Some of the most critical coating measurements occur in places standard probes cannot access. For complex geometries, internal diameters, grooves, tight corners, and recessed surfaces, a specialized probe is essential. The Nuicon EC770P Pen Probe Coating Thickness Gauge is engineered specifically for these challenges, delivering high-accuracy measurement performance through a slim, durable pen-style probe designed for precision in restricted spaces.
Provides accurate, stable, and repeatable coating measurements even in areas traditional probes cannot reach. Ideal for applications requiring precision inside cavities, narrow features, or complex metal components.
Rotatable 128×128 LCD and intuitive menu for easy operation in any position.
Accurate coating measurement on steel and non-ferrous metals, even after repositioning.
Automatically detects ferrous and non-ferrous substrates for accurate measurement.
Displays max, min, average, and standard deviation for better coating analysis.
Operation: Menu-driven, rotatable LCD
Probe: Slim pen-type
Measurement: Magnetic (steel), eddy current, auto Fe/NFe
Performance: 0–2000 µm | ±(2% + 1 µm) | 1 µm resolution
Display: LCD with alarm backlight
Data: 2000 readings, 5 groups, USB
Calibration: Zero, multi-point, foil
Power: AA/AAA batteries
Temperature: 0°C to 50°C
Compliance: CE, RoHS, ISO 2178, ISO 2360
The EC770P is the definitive internal pipe coating gauge and an essential tool for detailed manufacturing inspections.
Complex Components: Coating inspection in recesses, grooves, tubes, curved features, and internal sections.
Production QC: Routine measurements on painted, plated, or powder-coated surfaces during manufacturing.
Incoming Inspection: Quick verification of coating consistency on parts from suppliers.
Repair and Finishing Shops: Pre- and post-coating checks where internal or restricted-access measurements are required.
Options available: For rough surfaces, for high precision, for non-metal substrates, for tight or hard-to-reach areas.
Trust lab-grade precision; featuring 0.1μm resolution and NIST certification for critical aerospace validation.
Get into the tight spots; this pen-style probe measures inside pipes and on curved surfaces others can’t reach.
Master non-destructive testing on plastics and composites with advanced ultrasonic technology.
For advanced analysis when you need to measure the individual thickness of paint, primer, and other layers.
A rugged, all-purpose gauge with auto-detection, perfect for demanding on-site job inspections.
A smart upgrade; use our durable, high-performance probes with your existing Elcometer 456 base.
Simplify quality control; its one-button operation delivers instant pass/fail results right on the line.
Maximize value without sacrifice; get dependable ±3% accuracy for everyday automotive and shop use.
The EC770P is designed for small diameter inspection, reliably measuring inside pipes with an internal diameter of 30mm or greater.
The probe features a hardened, wear-resistant ruby tip designed for durability and a long operational life in industrial settings.
Yes, it features automatic substrate detection, making it fast and easy to measure on mixed-metal components.
Yes, it comes with a flexible 1.5-meter (5-foot) cable, providing ample reach for complex inspection tasks.
